HVAC Components
Professional - 3D - eLearning
Demonstrations of various HVAC related components, based off client provided CAD renders, and manual schematics. These models were built using Blender 3D, and the animation renders were used as additional graphics in Articulate Storyline courses.
Animated.
This video showcases some of the ways the 3D models were presented. To aid in the presentation of how an HVAC system works, colour coded animations were added to show the temperature and state of the refrigerant gases.
Below, you will find additional renders of the HVAC components.
Reversing valve cutaway.
Reversing valve with refrigerant gases.
Expansion Valve cutaway with refrigerant flows.
Cutaway of indoor coil in Cooling Mode.
